Intake system Carbon | fits BMW M5/M8 (F90/F91/F92/F93) 600hp S63 | Eventuri

Facts:
Acceleration time: 60-130mph Reduced by 0.22 seconds
Max. Flow rate per airbox at 28? H2O: Standard 620 CFM, Eventuri 736 CFM
Material: Carbon
Manufacturer: Eventuri
Parts certificate: A certificate is available for this product for certain regions and vehicles (details below)

The F90 Eventuri intake system has been developed through extensive real-world testing and airflow simulation analyses. Now in the updated V2 design, it features sealed filter housings to maintain a more stable IAT even when stationary. The new covers that seal the housings, in conjunction with our blade and shield combination, provide unrestricted airflow while maintaining low IATs through cold air saturation. Our large front air scoops channel ambient air directly into the intake area, ensuring that the engine does not suffer from heat soak. In addition, our gold-coloured, heat-reflecting shields have integrated flow guides that direct the ambient air from the blades into the filters. We have also managed to increase the cross-sectional area of the inlet pipe by over 30% compared to the standard inlet, as it passes through the openings in the struts.

The Eventuri difference
The F90 Eventuri system uses our patented carbon fibre housings with our bespoke Gen 2 filters, providing an aerodynamically efficient airflow path from the filter to the turbos. Not just another cone filter with a heat shield, but a unique design that creates the Venturi effect and maintains laminar flow conditions to reduce turbo drag.

Internal volume
Another important design feature of the inlet housings is the internal volume of the tubes as they pass through the struts. On the F90, the airbox system must pass through an oval opening in the strut brace on each side before reaching the turbo inlets. We have managed to increase the internal size of our inlets at this junction, resulting in more available volume for the turbos and therefore less restriction. The increase in cross-sectional area between the Eventuri and the standard airbox is 31% as follows:

Inner cross-sectional area of the intake pipe at the strut brace:
Standard airbox pipe = 6487 mm²
Eventuri intake pipe = 8497 mm²

Each intake system consists of:
2 x carbon fibre venturi housings with integrated pipes
2 x customised high-performance Generation 2 filters
2 x carbon fibre filter covers
2 x aluminium intake covers
2 x carbon fibre air scoops
2 x laser-cut heat shields, lined with gold heat reflective material
2 x laser-cut air ramps integrated into the heat shields
High-quality silicone couplings and OEM hose clamps

Parts certificate
The manufacturer's specifications apply for installation. An existing certificate is no guarantee that the product can also be installed in the corresponding vehicle.

A certificate is available for this product for the following regions and vehicles:
* DE/AT: Vehicle registration document, field K --- CH/LI: Vehicle licence, field 24
Country Model Type approval*
DE/AT BMW M5 e1*2007/46*1828*..
DE/AT BMW M5 Competition e1*2007/46*1828*..
DE/AT BMW M8 e1*2007/46*2019*..
DE/AT BMW M8 Competition e1*2007/46*2019*..

Compatible vehicles:
