Intake system Carbon | fits VAG 2.0 EA888 Gen.4 DNPA Golf 8 GTI, Octavia (NX), Cupra Leon (KL) 245hp | Eventuri
AED 5,712.12*
Delivery time: approx. 2-6 weeks. Exact delivery time on request*.
Finanzieren Sie ihren Einkauf über die Targobank.
Ratenrechner
Ihre Monatsraten
Kaufpreis:
Monatliche Rate:
Zinsen:
Gesamtbetrag inkl. Zinsen:
Facts:
Performance increase (standard Golf R): 10-13hp, 12-15Nm
Performance increase (tuned Golf R): 15-20hp, 25-30Nm
Material: Carbon fibre
Manufacturer: Eventuri
Parts certificate: A certificate is available for this product for certain regions and vehicles (details below)
The MK8 Golf GTi/R intake manifold is a complete revision of the standard intake manifold up to the turbo inlet. Taking inspiration from our RS3 intake, we have maximised the space available to create an intake that is suitable for all power levels, from standard specification through to high performance systems with hybrid or full frame turbos. This intake system has been developed to provide the highest possible flow rate whilst achieving the lowest possible intake temperatures. Each component has been designed to give the turbo a smooth and clear flow path. The restrictive standard intake pipe with a diameter of 73 mm is replaced by an intake pipe with a larger diameter of 94 mm. The filter itself has an outer diameter of 192mm or 7.5? with a filter area of over 110,000mm^2. The patented Venturi housing is designed to provide the largest possible internal volume for the available space in the Golf engine bay and provides laminar flow to the turbo pipe. Finally, the duct seals the filter opening at the windscreen, but is not restricted by the standard intake alone. We have raised the front of the duct to now create an additional opening behind the bonnet, equivalent to an extra 7? diameter hole for the inlet to draw from. The resulting system can significantly outflow the stock airbox while keeping intake temperatures to a minimum with the sealed design.
Dyno testing
Our MK8 Golf intake has been independently tested by a renowned tuner in the UK, Regal Autosport. A MK8 Golf R was tested in original condition and with a tuning box. The tests were carried out on the same day, with the standard airbox being tested first and then the Eventuri. No other changes were made to the car. The first graph shows the results with a stock map. As can be seen, there is a measurable gain across the rev range of up to 12bhp. This gain is noticeable even in a standard vehicle on the road due to better throttle response and faster acceleration. The second diagram shows the results when using a tuning box that increases the flow requirement of the intake system. The tuning box was used for both the standard airbox and the Eventuri intake, with no changes made between tests. With a higher flow requirement, the stock airbox places a greater restriction on the turbo, which is evident by the significant increase achieved with the Eventuri fitted. We now have a power increase of up to 20 hp and 30 Nm across the entire rev range, which is even more noticeable on the road. We expect the gains to be even greater with higher tuning levels.
The improvements are due to a combination of reasons:
1) The closed system keeps IAT levels low - the Golf's engine bay can heat up very quickly, so an open cone filter leads to an increase in IAT levels and therefore a loss of power.
2) The Venturi housing provides a smooth transition from the filter to the intake pipes, both of which are matched to an internal diameter of 94mm. This contributes to a more efficient operation of the turbo.
3) The entire system is made from pure pre-impregnated carbon fibre, which provides excellent insulation against heat and has smooth internal surfaces, unlike glass fibre, which has sharp resin lines.
Parts certificate
The manufacturer's specifications apply to installation. An existing certificate is no guarantee that the product can also be installed in the corresponding vehicle.
A certificate is available for this product for the following regions and vehicles:
* DE/AT: Vehicle registration document, field K --- CH/LI: Vehicle licence, field 24
Country Model Type approval*
DE/AT Audi S3 (8Y) e1*2007/46*2060*..
DE/AT Audi TTS (FV/FVP/8S e1*2001/116*0369*..
DE/AT Cupra Ateca LCI e9*2007/46*6394*..
DE/AT Cupra Formentor e9*2007/46*4008*..
DE/AT Cupra Leon e9*2007/46*3167*..
DE/AT Skoda Octavia RS e8*2007/46*0355*..
DE/AT Skoda Superb e8*2007/46*0317*..
DE/AT Volkswagen Arteon R e1*2007/46*1725*..
DE/AT Volkswagen Golf 8 GTI e1*2007/46*2014*..
DE/AT Volkswagen Golf 8 GTI CS e1*2007/46*2014*..
DE/AT Volkswagen Golf 8R e1*2007/46*2014*..
DE/AT Volkswagen Tiguan R e1*2001/116*0450*..
DE/AT Volkswagen Tiguan R (AD1) e1*2007/46*0487*..
Compatible vehicles:
| Vehicle | Vehicle type | Power | Engine capacity | Engine type |
| Audi Q3 (F3) | 45 TFSI quattro | 180kW / 245hp | 1984cm³ | DNPA |
| Cupra Formentor (KM) | 2.0 TSI | 180kW / 245hp | 1984cm³ | DNPA |
| Cupra Leon (KL) | 2.0 TSI | 180kW / 245hp | 1984cm³ | DNPA |
| Seat Tarraco (KN) | 2.0 TFSI 4Drive | 180kW / 245hp | 1984cm³ | DNPA |
| Skoda Octavia IV (NX) | RS 2.0 TFSI | 180kW / 245hp | 1984cm³ | DNPA |
| Skoda Kodiaq | RS 2.0 TSI 4x4 | 180kW / 245hp | 1984cm³ | DNPA |
| VW Golf 8 | GTI 2.0 TSI | 180kW / 245hp | 1984cm³ | DNPA |
| VW Tiguan II (AD) | 2.0 TSI 4motion | 180kW / 245hp | 1984cm³ | DNPA |
